UC9101c

High and Low Side Power MOSFET Gate Driver IC

• Fully operation to +600V

• Gate driver supplies up to 20V per channel

• UVLO for Vcc

• 3.3V, 5V and 15V input logic compatible

• Tolerant to negative transient voltage dV/dt immunity

• Matched propagation delays for both channels

• V_OFFSET : 600V(max.)

• IO+/- : 120mA / 250mA

• Vout : 10V ~ 18V

• tONOFF : 150ns / 95ns (Typ.)

• Delay Match : 60ns

• Package : SOP-8
